The Insight Operators Group is open to anyone who owns, or has owned an Insight NG
Rules since we must:
1: NO flaming.
2: Don't be rude, Be polite, were all gentlemen.
3: NO B/S/T! This is NOT The Buy sell trade forum- Keep it that way.
4: Please- keep the hating to a minimum.
5: And have a little fun- were all friends here.
How to Join:
1. Post pics of your Insight NG,
2. Put a link to this thread or the Insight Owners Grop in your sig,
3. PM me letting me know you would like to join.
4. Oh yeah and SPREAD THE WORD.
Come on in and stay awhile.
Insight/ Victus Engine O-ring Chart with Latest Updates:
Board Settings are Key:
Insight number three was having issues with not shooting every time the trigger was pulled using older Valkeen paint Saturday, so Troubleshot the issue and resolved the issue with at least my marker. When I turned the eyes off, it shot almost normal ... The cause I don't understand, but here is what fixed it for me.
Turns out the Debounce was set to 2 ms, Mech Debouce was set to 3 and bolt delay was set to 15 from the factory (and also in the factory reset)
Both of my previous Insights were set to a Debounce of 12ms, Mech delay of 4 and Bolt Delay of 25 ms from the factory (also Factory reset settings) ...
After I set the new Insight to those settings it shot just fine and picked up all the trigger pulls ...
************** "Original" New (Vic Settings) What works well for me:
Debounce ... ******12ms ****** 2ms *********** 12ms
Mech Debounce ...***04 ******* 03 ************* 04
Trigger Filter ... **** 06 ******* 06 ************** 06
Dwell:*********** 9ms ****** 12ms ************ 10.5ms
Bolt Delay: ******* 25ms ***** 15ms ************ 25ms
BD Delay: ******** 8ms ****** 8ms ************* 8ms
I just took my Multicam Insight set it to the new Victory settings above and it behaved exactly the same as the newer Insight I received a few weeks ago. It would not pick up every trigger pull on Semi, and it would not Ramp ... well, it wouldn't sustain a ramp ... It would shoot a few, then pause ... like it wasn't seeing the paint, although it was ... it would exhibit the exact behavior that a few of you have reported.
Reset it to the original settings minus the Dwell I set to 10.5ms and it shot perfect again.
I honestly think it is a board settings issue and how they are interacting with the Insight Engine. It is the only thing that makes sense to me. It is reproducible on multiple Insights using the Victory Settings ... I'll try the BCA insight and see if it does the same thing.
I call them Victory settings because my newest VIS came with the 5.19bd flash and was set to
Debounce: 02ms
Mech Debounce: 03
Trigger Filter: 06
Bolt Delay: 15ms
Those setting work just fine with both the VIS and Vcom Engines, but seem to cause issues with the Insight engine. Bob thinks what is happening is the Bolt is moving rearward so fast that the lower settings of the Victory are not "seeing" that the bolt moved back and a ball dropped in which is causing the weird firing behavior.
Some have had success using 4C eyes with the Victory factory settings, Although you shouldn't need to buy a $50 upgrade to have your marker shoot like it should. Try the board settings above and see how they work for you.
