odd cycling issue

Alright gun worked perfectly fine at cup and after, but i wasnt happy with the pressure being so high with the lurker bolt.

So today i cleaned everything and relubed, changed the dwell to 5.5ms, pressure around 160 and tried using the long boss spring, also changed out all the guide orings to the infamous ones. Went to shoot and the ball prob went 30ft, changed the pressure to 180 and the ball blew up all in the breach, so i cleaned it all out and tried again but to no luck the ball blew up again.

Cleaned everything and changed the last guide oring to one included with the lurker bolt and now the gun doesnt even cycle, it just blows air, I know the bolt is suppose to actually move forward and cycle so this is odd to me and have never had this kind of problem.

So this is where i need a little help
__________________
quit D1 college soccer to get back into paintball

AsylumTrueballers
Paintball Asylum
Torres Productions
mfarmy is offline   Reply With Quote
Old 12-01-2012, 07:45 PM #2
private_silver
Fire and Forget.

private_silver's Avatar

Join Date: May 2011
Location: Pennsylvania
private_silver is an NCPA player
private_silver plays in the APPA D5 division
Isn't lurker's bolt made to be used with the stock spring, not boss's?
__________________
Dust Black Axe w/ white accent
14" Freak Kit
Spire with CrownSF
Crossfire 68/45 w/ Stealth
private_silver is offline   Reply With Quote
Old 12-01-2012, 08:14 PM #3
Lurker27
Engineering the Future

Lurker27's Avatar

Join Date: Jun 2003
Annual Supporting Member
Lurker27 is a Mega Moderator
Lurker27 is a Supporting Member
 has been a member for 10 years
Lurker27 posts videos on PbNation
Lurker27 has been published on the PbNation Youtube Channel
That shouldn't be the issue. Bolt related issues are always friction or seal.


Bolt guide rings: are they sealing? How is the friction by hand?

Spacer: is it snugly locked in to the groove? Could the be lube behind it deseating it?

Spacer to bolt fit: Is it snug on the bolt? This should be an extremely light seal. This seal must be lubed, which confused some since the INNER spacer oring is not lubed. Changing to an 015 here is acceptable.

Bolt to body fit: you can move just the bolt in the body with a sharpie marker. if there is a boor seal with the 017 outside on the bolt or the tip is creating too much friction, weird things can happen.

I do recommend the stock spring, because the bolt spring in part determines poppet timing.

The ideal lurker setup barely seals on all the rings, for very low friction. When customers have problems I will hand fit the bolt and orings myself and send it back, this produces the best possible results. You can do it yourself as well, but it sometimes requires lots of orings.

I also sometimes do this:

1. Apply metal polish to the dynamic orings you want to break in (I highly recommend against valve orings)
2. Cycle the parts back and forth by hand while twisting for a couple of minutes
3. Carefully remove the orings and wash them thoroughly with soap and water (dish soap works well)
4. Apply a tiny bit of lube in the oring grooves then reinstall orings in the original grooves
5. Lube and re-assemble

Ryan
__________________
World's Best Hard-Parts Upgrades!
EigenBarrels, Mini, AXE, Intimidators, DM, Shocker
Lurker27 is offline   Reply With Quote
Old 12-01-2012, 08:34 PM #4
mfarmy


mfarmy's Avatar

Join Date: Jul 2009
Location: Franklin, TN
mfarmy plays in the PSP
mfarmy plays in the APPA D3 division
this is my set up right here
__________________
quit D1 college soccer to get back into paintball

AsylumTrueballers
Paintball Asylum
Torres Productions
mfarmy is offline   Reply With Quote
Old 12-01-2012, 08:35 PM #5
mfarmy


mfarmy's Avatar

Join Date: Jul 2009
Location: Franklin, TN
mfarmy plays in the PSP
mfarmy plays in the APPA D3 division
the bolt fits snug on the bolt guide, have to pull on it a little to pull it off. it fits fine on the spacer and with little force can be pulled up the spacer oring. Spacer is sitting snug, I can't even pull it off, bolts moves just fine in the breach with pushing it through with my finger

and i am using the stock spring
__________________
quit D1 college soccer to get back into paintball

AsylumTrueballers
Paintball Asylum
Torres Productions
mfarmy is offline   Reply With Quote
Old 12-01-2012, 09:06 PM #6
SNAKESNIPER (Banned)


Join Date: Nov 2011
Location: Toronto
The Boss long spring has almost as much tension as the stock one. I'd try maybe the medium or even the short spring. Less tension = more velocity at lower pressure, but a bit of a rougher shot. It's a trade-off.

Your o-ring setup is exactly like mine, assuming the black bolt guide o-ring is an 012. I use the Boss spacer and shock o-ring on my lurker bolt.
SNAKESNIPER is offline   Reply With Quote
Old 12-01-2012, 09:27 PM #7
mfarmy


mfarmy's Avatar

Join Date: Jul 2009
Location: Franklin, TN
mfarmy plays in the PSP
mfarmy plays in the APPA D3 division
yep one of the 012 that lurker included. Tried the stock, long, and short and it just blew air, wouldnt cycle forward and how i know is because i stuck my finger in the breach haha

and on the bolt i have the white shock absorber, boss shock oring
__________________
quit D1 college soccer to get back into paintball

AsylumTrueballers
Paintball Asylum
Torres Productions
mfarmy is offline   Reply With Quote
Old 12-01-2012, 09:38 PM #8
SNAKESNIPER (Banned)


Join Date: Nov 2011
Location: Toronto
poppet o-ring?
SNAKESNIPER is offline   Reply With Quote
Old 12-01-2012, 09:39 PM #9
mfarmy


mfarmy's Avatar

Join Date: Jul 2009
Location: Franklin, TN
mfarmy plays in the PSP
mfarmy plays in the APPA D3 division
it was fine, took it out and cleaned it off and lubed it, no leaks or anything
