11-30-2012, 08:06 PM
|
#127
|
|
|
Thanks pote. Wanted to know if a g5 bolt would work in a g4. The g5 stem looks longer, Does g5 bolt maintain contact with with g5 bolt stem through complete bolt cycle and just dump through holes?
|
|
|
|
11-30-2012, 08:07 PM
|
#128
|
|
|
Quote:
Originally Posted by GraniteGargoyle
Comes with the pressure gauge?
|
oh, sorry big guy, wasnt included, just wanted to show that the threads are backwards compatible to the PMD... |
|
|
|
|
11-30-2012, 08:08 PM
|
#129
|
|
|
Quote:
Originally Posted by SyLLabuz
oh, sorry big guy, wasnt included, just wanted to show that the threads are backwards compatible to the PMD...
|
Still not bad if you already have one. |
|
|
|
|
11-30-2012, 08:16 PM
|
#130
|
|
|
Quote:
Originally Posted by van457
Thanks pote. Wanted to know if a g5 bolt would work in a g4. The g5 stem looks longer, Does g5 bolt maintain contact with with g5 bolt stem through complete bolt cycle and just dump through holes?
|
im not pote...
to answer your question...
[IMG]  [/IMG]
[IMG]  [/IMG] |
|
|
|
|
11-30-2012, 10:17 PM
|
#131
|
|
Up the Irons
Join Date: Jul 2008
Location: Michigan
|
post those pics in the bolt kit thread ASAP!
__________________
COLORS Paintball -
Dirty Dogs
Proudly Sponsored by Yeti PB - Balls Out Photography DPOT: Hotter than a 2 peckered billy goat
Alien Independence - MacDev GT - Super Charged Closer KIP WE MISS YOU <3
|
|
|
|
|
11-30-2012, 10:50 PM
|
#132
|
|
|
Quote:
Originally Posted by SyLLabuz
|
Umm, that pressure gauge is from G3 og G4 ? |
|
|
|
|
12-01-2012, 03:30 AM
|
#133
|
|
Join Date: Jun 2009
Location: France
|
Will it be possible to buy the new bolt and back cap separately, as upgrades for the G4 ?
|
|
|
|
|
12-01-2012, 04:09 AM
|
#134
|
|
|
Thanks syllabuz. I guess the both bolt diameter and the bolt stop location is the same also? Could you also measure stem distance off inside of back cap? Thanks man.
|
|
|
|
|
12-01-2012, 09:22 AM
|
#135
|
|
?CustomizationSpecialist?
Join Date: Dec 2003
Location: Altoona
|
honestly other than bolt stick issues caused by too much lube on the back cap I can't really see much of a difference between the g4 and g5 bolts function wise. If you use an un-modded pmd you are also going to have to use the stock g4 bolt. The longer shaft on the g5 back cap is to compensate for those holes in the new bolt engine. If you used the g5 bolt with a g4 pmd the holes would drop off the stem oring too early and you would get a lot of air going up the feedneck due to the bolt not being forward that extra 1/4" and sealing into the front oring.....
__________________
R.I.P. Sean Speicher #22 R.I.P.
|
|
|
|
|
12-01-2012, 09:47 AM
|
#136
|
|
?CustomizationSpecialist?
Join Date: Dec 2003
Location: Altoona
|
__________________
R.I.P. Sean Speicher #22 R.I.P.
|
|
|
|
|
12-01-2012, 10:31 AM
|
#137
|
|
Up the Irons
Join Date: Jul 2008
Location: Michigan
|
the difference is a bigger dump chamber and better flow of air, its obvious. A big reason the techt engine has such big gains is because of how the air actually flows through the bolt.
basically what ive gotten from this is that the bolts are all interchangeable but they require having their respective backcaps as well. cant just run a g5 bolt without a g5 backcap, not a big deal.
if the trigger and board were also compatible (which i dont think they are just from looking at online pictures) you could just buy all three parts from DP but im sure the cost would be higher than whhat its worth when the entire gun is $330
__________________
COLORS Paintball -
Dirty Dogs
Proudly Sponsored by Yeti PB - Balls Out Photography DPOT: Hotter than a 2 peckered billy goat
Alien Independence - MacDev GT - Super Charged Closer KIP WE MISS YOU <3
|
|
|
|
|
12-01-2012, 10:35 AM
|
#138
|
|
?CustomizationSpecialist?
Join Date: Dec 2003
Location: Altoona
|
other differences to the body and acc include...
A series of ridges inside the body on the g5
where it is smooth on the g4
Upgraded thumb wheel and rubber bumper to help minimize wear on the lever
Gone are the feedneck ridges and replaced with wedges...
The raps lever was beefed up
A small bumper was added to minimize wear on the raps lever
The inlet hole was slotted and moved inside the raps
Super milled out under the eye covers
New "flat" eyes ala Fx
New board layout
__________________
R.I.P. Sean Speicher #22 R.I.P.
|
|
|
|
|
12-01-2012, 11:27 AM
|
#139
|
|
Disciple of the dark side
Join Date: Jan 2010
Location: Central Coast, CA
|
Are those ridges recessed into the wall of that part? Would increasing the volume that the solenoid has to fill when pushing the bolt back do anything to the speed at which it returns?
__________________
"When in doubt, just use C4"
|
|
|
|
|
12-01-2012, 11:33 AM
|
#140
|
|
?CustomizationSpecialist?
Join Date: Dec 2003
Location: Altoona
|
I really have no idea what so ever what those deep ridges do....it makes my brain hurt thinking about such things this early in the day, after another 2-3 rockstars I'll be thinking more clearly
__________________
R.I.P. Sean Speicher #22 R.I.P.
|
|
|
|
|
12-01-2012, 12:45 PM
|
#141
|
|
gun whore addict
Join Date: Nov 2007
Location: Southern California
|
I would say the new bolt never loses contact with the bolt stem. It looks like it uses the holes to dump the chamber instead of floating off the bolt stem like it does with the other g series.
|
|
|
|
|
12-01-2012, 01:17 PM
|
#142
|
|
|
Quote:
Originally Posted by AndrewTheWookie
Are those ridges recessed into the wall of that part? Would increasing the volume that the solenoid has to fill when pushing the bolt back do anything to the speed at which it returns?
|
Quote:
Originally Posted by Pote
I really have no idea what so ever what those deep ridges do....it makes my brain hurt thinking about such things this early in the day, after another 2-3 rockstars I'll be thinking more clearly
|
WARNING:
to all those who are thinking of putting the G4/spec r TechT bolt engine to the new G5,
it will fit, but THE RIDGES MILLED IN THE BREECH OF THE G5 WILL SHRED THE O-RING ON THE BOLT ENGINE.
that is all.
Last edited by SyLLabuz : 12-01-2012 at 04:05 PM.
|
|
|
|
|
12-01-2012, 02:32 PM
|
#143
|
|
|
Thanks for pics and measurments pote.I would agree with disturbed bolt prob. never leaves stem. It's prob quieter than stock g4 bolt due to the way it dumps air, 90 degrees dump to ball/barrel plane. May be a tad more gradual air dump, less pop becuse holes open a little more gradual vs. g4 bolt. To bad techt bolt engine dosen't seem to work with g5.
Last edited by van457 : 12-01-2012 at 07:42 PM.
|
|
|
|
|
12-01-2012, 02:42 PM
|
#144
|
|
Disciple of the dark side
Join Date: Jan 2010
Location: Central Coast, CA
|
Quote:
Originally Posted by SyLLabuz
WARNING:
to all those who are thinking of putting the G4/spec r bolt engine to the new G5,
it will fit, but THE RIDGES MILLED IN THE BREECH OF THE G5 WILL SHRED THE O-RING ON THE BOLT ENGINE.
that is all.
|
Since the bolt has no o-rings on it, which o-ring will it shred?
Never mind, I was thinking of the stock bolt, not the techt engine.
__________________
"When in doubt, just use C4"
Last edited by AndrewTheWookie : 12-01-2012 at 02:48 PM.
|
|
|
|
|
12-01-2012, 02:50 PM
|
#145
|
|
Join Date: Jun 2009
Location: France
|
Could somebody test the efficiency of a G4 with a G4 stock bolt engine and with a G5 bolt engine to compare ?
|
|
|
|
|
12-01-2012, 03:32 PM
|
#146
|
|
Up the Irons
Join Date: Jul 2008
Location: Michigan
|
thats alot of paint bro
__________________
COLORS Paintball -
Dirty Dogs
Proudly Sponsored by Yeti PB - Balls Out Photography DPOT: Hotter than a 2 peckered billy goat
Alien Independence - MacDev GT - Super Charged Closer KIP WE MISS YOU <3
|
|
|
|
|
12-01-2012, 04:22 PM
|
#147
|
|
|
Quote:
Originally Posted by AndrewTheWookie
Since the bolt has no o-rings on it, which o-ring will it shred?
Never mind, I was thinking of the stock bolt, not the techt engine.
|
sorry, I wasnt specific, I put my extra Techt bolt engine in the G5 and aired it up, major bolt stick right away, I thought a little lube might help, I degassed, pulled out the bolt and noticed that the O ring on the bolt had a chunk eaten out, then I remembered the ridges milled in the breech. I guess its back to the drawing boards for Techt.
And another thing, they changed the locations of the ASA vent holes, from above the ASA in the current RAPS to the bottom of the new ASA.
so no more ASA's blowing orings.  |
|
|
|
