Old 06-25-2012, 10:44 AM #1
Shooter28
PEACE

Shooter28's Avatar

Join Date: Jul 2007
Location: CENTRAL FLORIDA
Shooter28 plays in the PSP
Shooter28 plays in the APPA D3 division
Shooter28 supports DLX Technology
Shooter28 supports Empire
Leak from reg vent - the 'gat'

Recently picked up my first angel, must say I'm quite impressed. But, it has developed a small leak from the vent hole on the hpr. I've replaced the orings on the mini reg housing, lubed them, and reinstall'd. The leak persists and am curious to know if it could be caused by something else or if the orings I'm using have to be the problem.

Any help would be greatly appreciated.
__________________
Rebel.Renegade. Must stay paid.
sh(--)ker Owners v.LXII
Macdev
ΞΞ

R.I.P. Rob Kerr 2/1/91 - 3/15/10 & {HSP}
Gun Sale Thread | SHOCKER PARTS!!! | My gun collection | D00M.
Shooter28 is offline   Reply With Quote
Old Sponsored Links Remove Advertisement
Advertisement
Old 06-25-2012, 10:56 AM #2
greatwolf329
still sick of idiots

greatwolf329's Avatar

Join Date: Feb 2007
Location: Chicago, IL
Do you mean the vent hole on the HPR/mini reg? If so, pull the small piston and shim stack piston and lube the o-rings on it.
__________________
greatwolf329 is offline   Reply With Quote
Old 06-25-2012, 11:44 AM #3
Ryan10
Father of 3

Ryan10's Avatar

Join Date: Nov 2010
Location: Philadelphia, PA
Using a low pressure tank as well?
Ryan10 is offline   Reply With Quote
Old 06-25-2012, 12:19 PM #4
Shooter28
PEACE

Shooter28's Avatar

Join Date: Jul 2007
Location: CENTRAL FLORIDA
Shooter28 plays in the PSP
Shooter28 plays in the APPA D3 division
Shooter28 supports DLX Technology
Shooter28 supports Empire
Wolf - yes. I wanted to ask before I pulled that c clip to take a gander.

Ryan - No, I put my hp tank on there.. user error I see.

I'll report back once I check out the piston.
Thanks
__________________
Rebel.Renegade. Must stay paid.
sh(--)ker Owners v.LXII
Macdev
ΞΞ

R.I.P. Rob Kerr 2/1/91 - 3/15/10 & {HSP}
Gun Sale Thread | SHOCKER PARTS!!! | My gun collection | D00M.

Last edited by Shooter28 : 06-25-2012 at 12:21 PM.
Shooter28 is offline   Reply With Quote
Old 06-25-2012, 12:59 PM #5
Shooter28
PEACE

Shooter28's Avatar

Join Date: Jul 2007
Location: CENTRAL FLORIDA
Shooter28 plays in the PSP
Shooter28 plays in the APPA D3 division
Shooter28 supports DLX Technology
Shooter28 supports Empire
Everything seemed to be in place, not oring damage, they weren't dry. Should I just clean/grease and reinstall, or something more while its apart? Because that clip ain't a joke
__________________
Rebel.Renegade. Must stay paid.
sh(--)ker Owners v.LXII
Macdev
ΞΞ

R.I.P. Rob Kerr 2/1/91 - 3/15/10 & {HSP}
Gun Sale Thread | SHOCKER PARTS!!! | My gun collection | D00M.
Shooter28 is offline   Reply With Quote
Old 06-25-2012, 01:22 PM #6
Methodcaptain


Join Date: Feb 2009
I would replace the small oring on the large and small piston. Grease them up, and re-install.

like you said, that clip is a pain, you may as well make sure you're putting it together for a long time.
__________________
TEAM METHOD - D.O.G.'s Boy's
Custom A1 fly collector (Looking for wonderboy a1 fly)

WANTED: Blue angel A1 grips
Wanted - Angel A1/SB/AR:K parts and markers broken or working
Methodcaptain is online now   Reply With Quote
Old 06-25-2012, 02:03 PM #7
Ryan10
Father of 3

Ryan10's Avatar

Join Date: Nov 2010
Location: Philadelphia, PA
I don't see the ball bearing. Is it still in there?? That should go in first before the rest of the guts.
Ryan10 is offline   Reply With Quote
Old 06-25-2012, 05:35 PM #8
dr.strangelove
The Angel Eye Doctor

dr.strangelove's Avatar

Join Date: May 2003
Location: Earth
 has been a member for 10 years
Leaks from the vent hole 99% of the time are caused by the reg spool o-rings. It's easy to get really tiny nicks in them when re-installing due to the threaded portion at the bottom of the foregrip housing, so don't rule that out just because the o-rings are new. Use plenty of grease on them. Large piston o-rings would be the next thing to check.

Removing the circlip from the reg becomes exponentially easier with a pair of circlip pliers. You can find them at just about any hardware or automotive store. If you plan on keeping this gun for any appreciable amount of time it'd be well worth picking up a pair. Make sure you get ones designed for internal circlips. The ones designed for external circlips are spring loaded to splay the clip out when squeezed - you want exactly the opposite. A pair of mini needle nose pliers will also work, although the clip has a tendency to want to slip off sometimes with them.
dr.strangelove is offline   Reply With Quote
Old 06-25-2012, 09:10 PM #9
Shooter28
PEACE

Shooter28's Avatar

Join Date: Jul 2007
Location: CENTRAL FLORIDA
Shooter28 plays in the PSP
Shooter28 plays in the APPA D3 division
Shooter28 supports DLX Technology
Shooter28 supports Empire
Quote:
Originally Posted by Ryan10 View Post
I don't see the ball bearing. Is it still in there?? That should go in first before the rest of the guts.
It was in the housing still, but good looking out
Quote:
Originally Posted by dr.strangelove View Post
Leaks from the vent hole 99% of the time are caused by the reg spool o-rings. It's easy to get really tiny nicks in them when re-installing due to the threaded portion at the bottom of the foregrip housing, so don't rule that out just because the o-rings are new. Use plenty of grease on them. Large piston o-rings would be the next thing to check.
I replaced the out side orings again, and lubed the others. I turned the reg with the threads when installing it this time. Now leak free almost certain I got a small cut the first time, like you said.
Quote:
Removing the circlip from the reg becomes exponentially easier with a pair of circlip pliers. You can find them at just about any hardware or automotive store. If you plan on keeping this gun for any appreciable amount of time it'd be well worth picking up a pair. Make sure you get ones designed for internal circlips. The ones designed for external circlips are spring loaded to splay the clip out when squeezed - you want exactly the opposite. A pair of mini needle nose pliers will also work, although the clip has a tendency to want to slip off sometimes with them.
I used a pair of needle noose, wasnt too terrible.

Thanks Dr.
__________________
Rebel.Renegade. Must stay paid.
sh(--)ker Owners v.LXII
Macdev
ΞΞ

R.I.P. Rob Kerr 2/1/91 - 3/15/10 & {HSP}
Gun Sale Thread | SHOCKER PARTS!!! | My gun collection | D00M.
Shooter28 is offline   Reply With Quote
Old 06-25-2012, 10:42 PM #10
dr.strangelove
The Angel Eye Doctor

dr.strangelove's Avatar

Join Date: May 2003
Location: Earth
 has been a member for 10 years
Glad you got it sorted out
dr.strangelove is offline   Reply With Quote
Old 09-16-2012, 01:47 AM #11
pinrey1025


pinrey1025's Avatar

Join Date: Aug 2012
Location: Bakersfield, CA
pinrey1025 has achieved Level 1 in PbNation Pursuit
same problem surfaced today on my speed 05. thank god for the search bar!!
