Old 05-22-2015, 07:57 PM #1
WoodChuck65


Join Date: Jun 2007
Location: Jackson, Cali
WoodChuck65 owns a Planet Eclipse Ego
WoodChuck65 owns a Planet Eclipse Ego
Brand new geo 3.5. Defective?

I just acquired a brand new orange and silver geo 3.5 from my local field. It fires fine and everything but the eyes, on the screen it does the symbol of their being a fault each time the first trigger pull happens when its first turned on. Replaced the eyes thinking it was them. Still does the faulty symbol and goes away after turning eyes off and on or gun and on but comes back after the first trigger pull each time. What's wrong with this thing? Thanks
__________________
My Feedback
WoodChuck65 is offline   Reply With Quote
Old Sponsored Links Remove Advertisement
Advertisement
Old 05-22-2015, 08:19 PM #2
WoodChuck65


Join Date: Jun 2007
Location: Jackson, Cali
WoodChuck65 owns a Planet Eclipse Ego
WoodChuck65 owns a Planet Eclipse Ego
So the frame is all the way forward but the rear of the frame still has nearly a whole inch before its flush with the body but the rest of the frame is flush and even, but the rear of the frame won't go flush, and looks uneven with the bolt even in? You can see a lot of the orange of the extra body under the bolt cap even. I wonder if this could be the fault it's detecting, the frame not lining up? I must have a true defective geo 3.5
__________________
My Feedback
WoodChuck65 is offline   Reply With Quote
Old 05-22-2015, 08:24 PM #3
WoodChuck65


Join Date: Jun 2007
Location: Jackson, Cali
WoodChuck65 owns a Planet Eclipse Ego
WoodChuck65 owns a Planet Eclipse Ego
Won't let me post pics but I can email from my phone if PE chimes in
__________________
My Feedback

Last edited by WoodChuck65 : 05-22-2015 at 08:26 PM.
WoodChuck65 is offline   Reply With Quote
Old 05-22-2015, 08:51 PM #4
imped4now
BTFU

imped4now's Avatar

Join Date: Apr 2003
Location: Indianapolis
 has been a member for 10 years
Unbolt the frame, align it with the body and bolt it up. Ensure the eye wires aren't being pinched.....

I highly, highly doubt this is a marker issue....
__________________
OLD FEEDBACK>>40+ 0-
OlllllllO
I only argue with intelligent people.
imped4now is offline   Reply With Quote
Old 05-22-2015, 08:53 PM #5
WoodChuck65


Join Date: Jun 2007
Location: Jackson, Cali
WoodChuck65 owns a Planet Eclipse Ego
WoodChuck65 owns a Planet Eclipse Ego
Quote:
Originally Posted by imped4now View Post
Unbolt the frame, align it with the body and bolt it up. Ensure the eye wires aren't being pinched..... I highly, highly doubt this is a marker issue....
I did that five times already trying again and again. What's your email bud I'll send you the pics of what I'm talking about?

And also the frame is perfectly lined up. It's the *** end of the frame that isn't being flush. And no wires are pinched I made damn sure of that. Theirs just a gap between the frame and the bolt cap on the *** end of the frame. And I got brand new eyes and it still detects a fault. No pinched wires. Red eye is on the right side.
__________________
My Feedback
WoodChuck65 is offline   Reply With Quote
Old 05-22-2015, 08:58 PM #6
WoodChuck65


Join Date: Jun 2007
Location: Jackson, Cali
WoodChuck65 owns a Planet Eclipse Ego
WoodChuck65 owns a Planet Eclipse Ego
Also if I pull the trigger multiple times the noid cycles then every so often it misses and doesn't cycle for two times in a row. Doesn't do its normal click. Does it every 5 pulls or so.

Also when I booted it up too after bolting it back up the screen said planet eclipse geo and a bunch of gibberish all over the place on the screen and flashed on too fast before I could read more but it hasn't done that again at all. This thing is acting all sorts of funky .... ? I'm not sure it's a user error as I haven't even put more than 100 shots through it yet. Doesn't leak at all just detects a fault and the *** end of the frame isn't flush while the rest of the frame is perfectly flush.
__________________
My Feedback

Last edited by WoodChuck65 : 05-22-2015 at 09:03 PM.
WoodChuck65 is offline   Reply With Quote
Old 05-22-2015, 09:42 PM #7
warrior24
Team Rival

warrior24's Avatar

Join Date: Dec 2005
Location: Bend, OR
warrior24 owns a Planet Eclipse Lv1
Check the trigger, could be just a little off, open the from so you can see the trigger engaging,
__________________
Fort Rival Paintball Field - https://www.facebook.com/FortRival - Team Rival
warrior24 is offline   Reply With Quote
Old 05-22-2015, 09:54 PM #8
WoodChuck65


Join Date: Jun 2007
Location: Jackson, Cali
WoodChuck65 owns a Planet Eclipse Ego
WoodChuck65 owns a Planet Eclipse Ego
Quote:
Originally Posted by warrior24 View Post
Check the trigger, could be just a little off, open the from so you can see the trigger engaging,
Did that already. And the trigger is at stock adjustments. It goes far enough to be sensed plus a little further. And far enough to trigger the macro switch and a little further.
__________________
My Feedback
WoodChuck65 is offline   Reply With Quote
Old 05-22-2015, 10:15 PM #9
Viashino17
CSCA CIA PS3 PS4 MTG!

Viashino17's Avatar

Join Date: Sep 2013
Location: Somewhere in Los Angeles
Viashino17 owns a Planet Eclipse Geo
Viashino17 plays in the APPA beginner division
Viashino17 has achieved Level 1 in PbNation Pursuit
I know it's silly but, first things first. Did you replace the battery for a new Duracell or Energizer?
Viashino17 is offline   Reply With Quote
Old 05-22-2015, 10:18 PM #10
WoodChuck65


Join Date: Jun 2007
Location: Jackson, Cali
WoodChuck65 owns a Planet Eclipse Ego
WoodChuck65 owns a Planet Eclipse Ego
Quote:
Originally Posted by Viashino17 View Post
I know it's silly but, first things first. Did you replace the battery for a new Duracell or Energizer?
Old manian just asked the same exact thing and I smacked my head and declared no! And felt like Humpty Dumpty for a minute. Going to get a new one now
__________________
My Feedback
WoodChuck65 is offline   Reply With Quote
Old 05-22-2015, 10:36 PM #11
WoodChuck65


Join Date: Jun 2007
Location: Jackson, Cali
WoodChuck65 owns a Planet Eclipse Ego
WoodChuck65 owns a Planet Eclipse Ego
Two brand new Duracell 9 volts. Same problem persists with both of them.
__________________
My Feedback
WoodChuck65 is offline   Reply With Quote
Old 05-22-2015, 11:41 PM #12
BatmanLiera


Join Date: Mar 2013
Location: Chicago
Is the bolt sitting in the forward position?

Gas up the gun and see if it still does it
__________________
My Youtube Channel! (gameplay & shooting vids)
https://www.youtube.com/user/weroliera/videos
BatmanLiera is offline   Reply With Quote
Old 05-22-2015, 11:53 PM #13
WoodChuck65


Join Date: Jun 2007
Location: Jackson, Cali
WoodChuck65 owns a Planet Eclipse Ego
WoodChuck65 owns a Planet Eclipse Ego
Quote:
Originally Posted by BatmanLiera View Post
Is the bolt sitting in the forward position? Gas up the gun and see if it still does it
Figured it out but thank you. I like the friendly people here whom are actually help ful despise my stupid moments in which I say dumb things. Don't like the ones who like to make fun of me and drag it on and bring me down.

Thank you oldmanian, friendliest member in a long time and very very helpful.
__________________
My Feedback
WoodChuck65 is offline   Reply With Quote
Old 05-23-2015, 01:43 AM #14
Jack Wood


Jack Wood's Avatar

Join Date: Jul 2001
Location: Planet Eclipse, England
Annual Supporting Member
Jack Wood is a founding member
 has been a member for 10 years
Jack Wood works for a Paintball manufacturer
Jack Wood owns a Planet Eclipse GSL
Hi,

You posted in the middle of the night, lol

So I take it that what you were doing was trying this with the gun de-gassed?

When the gun is de-gassed the bolt slides forward and blocks the eyes and yes, you will get an eye default message every time.

Glad the Oldmanian got you sorted out before it drove you mad

By the way, the gibberish you saw on the screen that one time will have been the firmware information. If you press and hold the button just as it starts to power up it will display the firware revision and marger type etc

Jack
Jack Wood is offline   Reply With Quote
Old 05-23-2015, 08:47 AM #15
WoodChuck65


Join Date: Jun 2007
Location: Jackson, Cali
WoodChuck65 owns a Planet Eclipse Ego
WoodChuck65 owns a Planet Eclipse Ego
Perfect thank you Jack. And yeah I was doing it without the bolt in the gun and concluded that what I was doing wrong was when I tested the new eyes I kept my finger in the breech blocking the eyes after the trigger pull and it thought there was a fault because my finger was still their.
__________________
My Feedback
WoodChuck65 is offline   Reply With Quote
Old 05-23-2015, 09:12 AM #16
Jack Wood


Jack Wood's Avatar

Join Date: Jul 2001
Location: Planet Eclipse, England
Annual Supporting Member
Jack Wood is a founding member
 has been a member for 10 years
Jack Wood works for a Paintball manufacturer
Jack Wood owns a Planet Eclipse GSL
Yes, the eye logic is not straighforward. For the eyes to see a "true" cycle and call it valid it has to see a ball in the breech, then the gun fire, then a gap in the breech as the bolt retracts, and then a ball in the breech again.

If it doesn't see the gap between the first ball being fired and the second ball arriving in the breech from the loader, it flags it as a "fault" shot and the eyes default and go to the square eye brackets.
Jack Wood is offline   Reply With Quote
Old 05-23-2015, 09:21 AM #17
WoodChuck65


Join Date: Jun 2007
Location: Jackson, Cali
WoodChuck65 owns a Planet Eclipse Ego
WoodChuck65 owns a Planet Eclipse Ego
Quote:
Originally Posted by Jack Wood View Post
Yes, the eye logic is not straighforward. For the eyes to see a "true" cycle and call it valid it has to see a ball in the breech, then the gun fire, then a gap in the breech as the bolt retracts, and then a ball in the breech again. If it doesn't see the gap between the first ball being fired and the second ball arriving in the breech from the loader, it flags it as a "fault" shot and the eyes default and go to the square eye brackets.
See that's all new to me coming from an ego 7 where it didn't have that software. Also one question while your not busy. Why does the solenoid miss a cycle every 5 shots even in psp mode or nppl ramping or capped semi or uncapped semi when in opto mode but on switch it doesn't? I have cleaned the opto eyes and I have adjusted the trigger so it moves accordingly to be seen perfectly fine by the opto eyes on the board thinking the stock trigger adjustments may have been a little out of place
__________________
My Feedback
WoodChuck65 is offline   Reply With Quote
Old 05-26-2015, 09:02 PM #18
oldmanian
JLK 10/9/11

oldmanian's Avatar

Join Date: Aug 2003
Location: Fairview
Annual Supporting Member
oldmanian is a Supporting Member
 has been a member for 10 years
oldmanian donated to help Peyton Trent
oldmanian supports Bob Gurnsey
oldmanian supports our troops
oldmanian supports DLX Technology
Quote:
Originally Posted by WoodChuck65 View Post
...Thank you oldmanian, friendliest member in a long time and very very helpful...
Thanks, there are alot of helpful members here (as you see).

Quote:
Originally Posted by WoodChuck65 View Post
...Also one question while your not busy. Why does the solenoid miss a cycle every 5 shots even in psp mode or nppl ramping or capped semi or uncapped semi when in opto mode but on switch it doesn't? I have cleaned the opto eyes and I have adjusted the trigger so it moves accordingly to be seen perfectly fine by the opto eyes on the board thinking the stock trigger adjustments may have been a little out of place
This issue still vexes me. When you say miss a cycle, what exactly do you mean? It just doesn't register or it does but doesn't fully cycle and does it only happen during rapid firing or will it do it if you just pull, say once or twice per second?
__________________
***Support Joan's Reach***
Support Trisomy18.org ~ ~ Support Michaels Feat
Old Feedback +19/-0 -|- New Feedback +28/-0 -|- ebayFeedback +236/-0
Originally posted by Lurker27:" ...incompetence has no raw material..."
oldmanian is offline   Reply With Quote
Old 05-27-2015, 02:28 AM #19
Jack Wood


Jack Wood's Avatar

Join Date: Jul 2001
Location: Planet Eclipse, England
Annual Supporting Member
Jack Wood is a founding member
 has been a member for 10 years
Jack Wood works for a Paintball manufacturer
Jack Wood owns a Planet Eclipse GSL
It sounds like the TT filtering on the opto trigger is kicking in and cancelling a shot.

Lowering the debounce settings on opto will widen the "valid trigger pull" window and accept more trigger pulls as valid.

Personally I'd just stick it in micro and forget about it.

And the Ego7 had exactly the same eye logic as the Geo. In fact we have had the same eye logic for detecting valid shots since Ego5.

Right. Back to my vacation

Jack
Jack Wood is offline   Reply With Quote
Old 05-27-2015, 10:48 AM #20
WoodChuck65


Join Date: Jun 2007
Location: Jackson, Cali
WoodChuck65 owns a Planet Eclipse Ego
WoodChuck65 owns a Planet Eclipse Ego
Quote:
Originally Posted by Jack Wood View Post
It sounds like the TT filtering on the opto trigger is kicking in and cancelling a shot. Lowering the debounce settings on opto will widen the "valid trigger pull" window and accept more trigger pulls as valid. Personally I'd just stick it in micro and forget about it. And the Ego7 had exactly the same eye logic as the Geo. In fact we have had the same eye logic for detecting valid shots since Ego5. Right. Back to my vacation Jack
Oops! Enjoy your vacation thank you for your help, Jack!
__________________
My Feedback
WoodChuck65 is offline   Reply With Quote
