Old 01-20-2010, 10:40 PM #1
gunangel
blah blah blah

gunangel's Avatar

Join Date: Mar 2005
Location: Washington
Lucky Stage 5 and Hollowpoint

Hey guys, I just finished up my ion only to find that it vents air after 20-30 shots.

The ion has a lucky stage 5 body with a 5.1 back cap installed and a deadly wind hollowpoint bolt kit. the more i look at diagrams of what the level 5 should have internally the more it looks like i'm missing a few parts.

this is what i have with nothing left in the body:

the first 3 starting from the top left are symmetrical rings i found in the firing can, the next piece is the firing can with nothing in it, the 5th piece is the hollow point bolt, the first piece on the next row is a piece i found in the body, and last is the bolt stalk mated to the stage 5.1 back cap.

now correct me if i'm wrong but i'm missing a piece right? could someone point me towards which piece it is and where to find a replacement? and can someone tell me how to put in everything? like does the orientation of the symmetrical rings matter?

thank you very much!
__________________
F/S:
Micromag 2k9 setup, Non SP Ion
Wants: MONEY, X-valve, Nelspot 007, phantom parts
Powered By: APS, DZ, Paintball-Online
gunangel is offline   Reply With Quote
Old Sponsored Links Remove Advertisement
Advertisement
Old 01-20-2010, 10:56 PM #2
rjones1213


rjones1213's Avatar

Join Date: Nov 2005
Location: Saginaw, MI
rjones1213 is an NCPA player
rjones1213 plays in the APPA beginner division
rjones1213 has achieved Level 4 in PbNation Pursuit
do you have a bolt stop?
__________________
Old Feedback
I Do Cool Stuff

SVSU Paintball #14
rjones1213 is offline   Reply With Quote
Old 01-20-2010, 11:10 PM #3
gunangel
blah blah blah

gunangel's Avatar

Join Date: Mar 2005
Location: Washington
not sure, but what i have up there is pretty much all i have. the bolt is quite wobbly when it's on by itself.

the firebolt came with a black rubber piece on it, but my hollowpoint won't fit on or around it in any way if that's what the bolt stop is >.<
__________________
F/S:
Micromag 2k9 setup, Non SP Ion
Wants: MONEY, X-valve, Nelspot 007, phantom parts
Powered By: APS, DZ, Paintball-Online

Last edited by gunangel : 01-20-2010 at 11:30 PM.
gunangel is offline   Reply With Quote
Old 01-21-2010, 08:40 AM #4
evilpaintball311
zoom zoom

evilpaintball311's Avatar

Join Date: Sep 2007
Location: 850/407, FL
evilpaintball311 supports our troops
evilpaintball311 has achieved Level 1 in PbNation Pursuit
evilpaintball311 has perfected Level 1 in PbNation Pursuit
I have no clue what all the stuff is on the left. They look like top hat rings. All you need is the bolt, stalk, back cap, and front insert. The front insert is in the body most likely. Is you feel behind the feedneck inside the body you will feel and oring. That is were the front insert is.
__________________
evilpaintball311 is offline   Reply With Quote
Old 01-21-2010, 09:19 AM #5
openingact
I Live My Life 300 fps

openingact's Avatar

Join Date: May 2007
Location: Menasha, WI
What you have is what you need for the Hollowpoint to work on the Lucky Body. You don't even need the 3 symetrical rings. Those are just to decrease the air volume in the firing chamber.

You aren't missing anything
__________________
Christ Krew Sons of Thunder CPPA
openingact is offline   Reply With Quote
Old 01-21-2010, 11:48 AM #6
whswatty
But seriously... i got em

whswatty's Avatar

Join Date: Aug 2007
Location: Saginaw Michigan
I would suggest to install the bolt without the rings to start with and try to get it running reliably
__________________
"This isn't paintball.... This is bull$hit!!!"
whswatty is offline   Reply With Quote
Old 01-21-2010, 03:09 PM #7
gunangel
blah blah blah

gunangel's Avatar

Join Date: Mar 2005
Location: Washington
thanks for the replies thus far!

so the rings i don't need, got it.

the ring on the bottom left is the piece i pulled out from the body is that the front insert? everything else inside the body looks anodized.

i'll be trying it out when i get home.
__________________
F/S:
Micromag 2k9 setup, Non SP Ion
Wants: MONEY, X-valve, Nelspot 007, phantom parts
Powered By: APS, DZ, Paintball-Online
gunangel is offline   Reply With Quote
Old 01-21-2010, 03:28 PM #8
openingact
I Live My Life 300 fps

openingact's Avatar

Join Date: May 2007
Location: Menasha, WI
Quote:
Originally Posted by gunangel View Post
thanks for the replies thus far!

so the rings i don't need, got it.

the ring on the bottom left is the piece i pulled out from the body is that the front insert? everything else inside the body looks anodized.

i'll be trying it out when i get home.
The bottom left peice should be in there though it's not needed. IIRC it helps direct the air flow better to increase the performance of the HP.
__________________
Christ Krew Sons of Thunder CPPA
openingact is offline   Reply With Quote
Old 01-21-2010, 05:04 PM #9
rjones1213


rjones1213's Avatar

Join Date: Nov 2005
Location: Saginaw, MI
rjones1213 is an NCPA player
rjones1213 plays in the APPA beginner division
rjones1213 has achieved Level 4 in PbNation Pursuit
there is another piece that should still be in the body, it's a small firing can that's the length of the front part of the bolt and should still be in the body

I would take all the pieces out of the gun and assemble them to check oring tolerances and replace any orings that are bad
__________________
Old Feedback
I Do Cool Stuff

SVSU Paintball #14
rjones1213 is offline   Reply With Quote
Old 01-21-2010, 06:19 PM #10
gunangel
blah blah blah

gunangel's Avatar

Join Date: Mar 2005
Location: Washington
hmm not seeing anything else in the body, here are pics for proof





just tried to shoot, without the three rings in the firing can the marker just vents
__________________
F/S:
Micromag 2k9 setup, Non SP Ion
Wants: MONEY, X-valve, Nelspot 007, phantom parts
Powered By: APS, DZ, Paintball-Online
gunangel is offline   Reply With Quote
Old 01-21-2010, 06:31 PM #11
rjones1213


rjones1213's Avatar

Join Date: Nov 2005
Location: Saginaw, MI
rjones1213 is an NCPA player
rjones1213 plays in the APPA beginner division
rjones1213 has achieved Level 4 in PbNation Pursuit
http://www.pbnation.com/showthread.php?t=2111150
as you can see there is a firing can in both stage 5 and 5.1 bolt kits, hopefully that helps
__________________
Old Feedback
I Do Cool Stuff

SVSU Paintball #14
rjones1213 is offline   Reply With Quote
Old 01-21-2010, 06:59 PM #12
gunangel
blah blah blah

gunangel's Avatar

Join Date: Mar 2005
Location: Washington
that's the diagram that made me think i was missing the part, but i admit i am new to ions and i trust the previous seller so if you guys say it's in there i trust you folk found an o-ring in the body so i guess it's in there.

i replaced the o-rings on the hp bolt stock, removed the three firing can rings, and it holds air and shoots. i didn't get a chance to put any rounds through it or walk it extensively, but there is almost no kick it's pretty sweet!

thanks for the help! and hopefully i'll get some air this weekend. so will i want to insert the three rings at some point? iirc decreasing volume gets better efficiency?
__________________
F/S:
Micromag 2k9 setup, Non SP Ion
Wants: MONEY, X-valve, Nelspot 007, phantom parts
Powered By: APS, DZ, Paintball-Online

Last edited by gunangel : 01-21-2010 at 07:02 PM.
gunangel is offline   Reply With Quote
Old 01-21-2010, 07:56 PM #13
rjones1213


rjones1213's Avatar

Join Date: Nov 2005
Location: Saginaw, MI
rjones1213 is an NCPA player
rjones1213 plays in the APPA beginner division
rjones1213 has achieved Level 4 in PbNation Pursuit
I would get it shooting without them and then put them in and retune the gun

they should help make it more efficient but it will run at a slightly higher pressure
__________________
Old Feedback
I Do Cool Stuff

SVSU Paintball #14
rjones1213 is offline   Reply With Quote
Old 01-21-2010, 08:39 PM #14
Muff Muff
Muff Muff OUT

Muff Muff's Avatar

Join Date: Nov 2007
Location: CC/Arlington, Texas
Top hat rings increase pressure by reducing the volume of the firing chamber, but since there is less volume to fill, you use less air, making the gun more efficient.
__________________
WHATABURGER
"Idiots neither forgive, nor forget. Intelligent people forgive and forget, but a true Wise Man forgives, but NEVER forgets."
Muff Muff is offline   Reply With Quote
Old 01-22-2010, 12:36 AM #15
gunangel
blah blah blah

gunangel's Avatar

Join Date: Mar 2005
Location: Washington
i c i c i'll be printing out the max's tuning guide with me and i'll mess aroud a bit.

^dude your avvy is disturbing lol
__________________
F/S:
Micromag 2k9 setup, Non SP Ion
Wants: MONEY, X-valve, Nelspot 007, phantom parts
Powered By: APS, DZ, Paintball-Online
gunangel is offline   Reply With Quote
Old 01-22-2010, 08:57 AM #16
Muff Muff
Muff Muff OUT

Muff Muff's Avatar

Join Date: Nov 2007
Location: CC/Arlington, Texas
It's not me, it's someone else. I get that a lot too lol.
__________________
WHATABURGER
"Idiots neither forgive, nor forget. Intelligent people forgive and forget, but a true Wise Man forgives, but NEVER forgets."
Muff Muff is offline   Reply With Quote
Old 01-22-2010, 01:04 PM #17
dr. j. h. gerbert
Mob Paintball

dr. j. h. gerbert's Avatar

Join Date: Mar 2008
Location: Buffalo, NY
FYI, if you run the hollow point bolt at "too high" of a pressure, it will literally rip the main o-ring right off the stalk. "Too high" could be anywhere from 160 psi to 180 psi. If you stay below that you should be okay.
__________________
N I C E Cyborg RX F/S
dr. j. h. gerbert is offline   Reply With Quote
Old 01-28-2010, 10:58 PM #18
gunangel
blah blah blah

gunangel's Avatar

Join Date: Mar 2005
Location: Washington
hmm i was running it at 200 O.o, i thought smaller firing chamber meant you had to increase pressure.

i purchased a gcpb body that i'm going to swap the parts into and i'll play around with the pressure then (better color match and it came with detents and laser eyes ).

what should i be aiming for then for input psi and dwell?
hollowpoint bolt
lucky body
mac noid
scenario dreams t-board
qev's
__________________
F/S:
Micromag 2k9 setup, Non SP Ion
Wants: MONEY, X-valve, Nelspot 007, phantom parts
Powered By: APS, DZ, Paintball-Online
gunangel is offline   Reply With Quote
Old 01-28-2010, 11:12 PM #19
dr. j. h. gerbert
Mob Paintball

dr. j. h. gerbert's Avatar

Join Date: Mar 2008
Location: Buffalo, NY
200 is most likely too high for the HP bolt. Try about 140-160. Mine rips off the stalk at about 170 or so
__________________
N I C E Cyborg RX F/S
dr. j. h. gerbert is offline   Reply With Quote
Old 01-29-2010, 12:00 AM #20
gunangel
blah blah blah

gunangel's Avatar

Join Date: Mar 2005
Location: Washington
ooh, that's a real low operation pressure, me likey hopefully i'll have success to report next weekend!
__________________
F/S:
Micromag 2k9 setup, Non SP Ion
Wants: MONEY, X-valve, Nelspot 007, phantom parts
Powered By: APS, DZ, Paintball-Online
gunangel is offline   Reply With Quote
Old 01-29-2010, 12:13 AM #21
rjones1213


rjones1213's Avatar

Join Date: Nov 2005
Location: Saginaw, MI
rjones1213 is an NCPA player
rjones1213 plays in the APPA beginner division
rjones1213 has achieved Level 4 in PbNation Pursuit
my lucky 5.1 w/ TechT L7 runs at 120 psi and 10ms dwell so since the hollowpoint is slightly lighter you should have around the same results

what dwell are you running? and was the 200 with all 3 rings in?

I don't have any tophat rings in my gun yet but I may try them for efficiency once I tune it better how it sits
__________________
Old Feedback
I Do Cool Stuff

SVSU Paintball #14
rjones1213 is offline   Reply With Quote
