Old 03-14-2016, 09:11 PM #1
noremaximus


Join Date: Feb 2016
E2 Orracle clapper solenoid stops responding

I'm having a small issue I hope. I just purchased an E2 Orracle and it seems to be having an issue with the clapper solenoid. When I start walking the trigger the clapper solenoid activates just fine, however after a few second it stops activating. I no longer hear the click from the clapper solenoid. This happens at different intervals. I can be walking the trigger and after 4-5 secs the clapper solenoid stops activating and in other occasions it might take 8 secs to stop working. Once it stops working I have a to wait a while before I the clapper solenoid starts working again. any ideas? Thanks.
noremaximus is offline   Reply With Quote
Old Sponsored Links Remove Advertisement
Advertisement
Old 03-14-2016, 10:09 PM #2
blackmagic71


blackmagic71's Avatar

Join Date: Jan 2005
Location: SE Minnesota
 has been a member for 10 years
What's your SON set at?

Seems like a silly question but, are you using fresh batteries?
blackmagic71 is offline   Reply With Quote
Old 03-15-2016, 01:16 AM #3
noremaximus


Join Date: Feb 2016
yes im using fresh batterys, and what does the SON stand for?
noremaximus is offline   Reply With Quote
Old 03-15-2016, 05:10 AM #4
vantrepes
The voices say I'm normal

vantrepes's Avatar

Join Date: Apr 2001
Location: Rochester NY
vantrepes is a founding member
 has been a member for 10 years
Pull the grip off the right side, and see if the noid core is getting stuck in the upward position. Sometimes, they can get gummed up, and need a cleaning.
Also, when it stops reacting, if you pull the cocking rod back, will the sear catch the hammer? If not, that also indicated that the noid core is stuck in the upward position.
vantrepes is offline   Reply With Quote
Old 07-19-2016, 12:04 PM #5
Bushy Shooter
J.

Bushy Shooter's Avatar

Join Date: Sep 2001
Location: North Jersey
 has been a member for 10 years
Sorry to resurrect a dead thread, I figured it was better than creating a new thread about the same issue.

I am having the same issue as noremaximus. By your description and my examination the solenoid core is gets stuck in the upward position. You mention pulling out the clapper solenoid and cleaning it. However, I've looked online, as well as my E2 manual and I don't see anything about cleaning it specifically. Is there a way to go about it specifically, or should I just kind of figure it out as I go tonight?
__________________
No, I still don't own a Bushmaster.
Bushy Shooter is offline   Reply With Quote
Old 07-19-2016, 02:36 PM #6
tacxplosion
Broke but never broken

tacxplosion's Avatar

Join Date: Sep 2007
Location: Guatemala (for real)
You just unscrew a set screw on the side and the clapper comes out the top (don't touch the set screw in the bottom), then just pull it apart (core from coil) and clean it. Clappers are much simpler than solenoid valves.
tacxplosion is offline   Reply With Quote
Old 07-19-2016, 02:38 PM #7
Bushy Shooter
J.

Bushy Shooter's Avatar

Join Date: Sep 2001
Location: North Jersey
 has been a member for 10 years
Sounds easy enough, I'll pull it all apart tonight. Thanks for the help.
__________________
No, I still don't own a Bushmaster.
Bushy Shooter is offline   Reply With Quote
Old 08-31-2016, 04:47 PM #8
tzzler44
Shocker Tech

tzzler44's Avatar

Join Date: Oct 2006
Location: Virginia
 has been a member for 10 years
tzzler44 has achieved Level 1 in PbNation Pursuit
tzzler44 has achieved Level 2 in PbNation Pursuit
tzzler44 is attending Decay of Nations VI
If that doesn't work make sure your sear spring isn't toast. I had to stretch mind out to get the sear to push the core back down.
__________________
****WTB 2011 VALKEN REDEMPTION TRAUMATIC PACK****
tzzler44 is offline   Reply With Quote
