Old 11-26-2011, 08:16 AM #442
brazy-u


Join Date: Jan 2002
 has been a member for 10 years


















brazy-u is offline   Reply With Quote
Old 11-26-2011, 08:45 PM #443
RabidHobo
projectile bacon?!

RabidHobo's Avatar

Join Date: Oct 2004
Location: North Carolina
RabidHobo owns a Planet Eclipse Geo
RabidHobo supports Team VICIOUS
RabidHobo has achieved Level 1 in PbNation Pursuit
RabidHobo has perfected Level 1 in PbNation Pursuit
hey Brazy,
could you just type up a little something about the things you post in your native language. google translate will work wonders.
RabidHobo is offline   Reply With Quote
Old 11-28-2011, 01:47 AM #444
brazy-u


Join Date: Jan 2002
 has been a member for 10 years
I'm on it
brazy-u is offline   Reply With Quote
Old 11-28-2011, 07:26 PM #445
brazy-u


Join Date: Jan 2002
 has been a member for 10 years










brazy-u is offline   Reply With Quote
Old 11-28-2011, 07:47 PM #446
brazy-u


Join Date: Jan 2002
 has been a member for 10 years















brazy-u is offline   Reply With Quote
Old 11-28-2011, 08:05 PM #447
brazy-u


Join Date: Jan 2002
 has been a member for 10 years




brazy-u is offline   Reply With Quote
Old 11-29-2011, 01:29 AM #448
sverref
#141 Finnerud

sverref's Avatar

Join Date: Jan 2008
Location: Norway
sverref supports Team VICIOUS
i cant understand the drawings but im fine with that because it looks rigth:p
__________________
Feedback
sverref is offline   Reply With Quote
Old 11-29-2011, 08:12 AM #449
brazy-u


Join Date: Jan 2002
 has been a member for 10 years




brazy-u is offline   Reply With Quote
Old 11-29-2011, 08:15 AM #450
brazy-u


Join Date: Jan 2002
 has been a member for 10 years
les lèvres sont légèrement moins saillantes pour réduire légèrement
l’épaisseur et le volume d’air utilisé pour le va et vient du bolt

le foamy est à tête plate pour : -1 limiter le jeu de la bille entre la tête de bolt et les anti double feed
-2 la lèvre de périphérie réduit la violence de la morsure sur la bille suivante

un bolt léger et offrant un peu plus de volume à la chambre (power tub) mais moins fiable

joint de .040 intégré au breech pour mieux isoler l’air au cul de la bille

cône d’entrée (de .700 au diamètre seléctioné ici .689)
(la distance du cône est définie par la
position de la bille quand le bolt l’a poussé avant l’expulsion)

petite lèvre pour isoler les vibrations du moteur avec l’eye pipe (afin de réduire le taux de
fêlure sur le plastique)

collet type MACDEV avec bourlet
(plus fiable et plus court qu’un collet
à visser du fait qu’il est d’un bloc )

biseau pour réduire le scalpage de bille

eye pipe type nt pour
mieux isoler l’air au cul
de la bille grâce au joint
de devant
brazy-u is offline   Reply With Quote
Old 11-29-2011, 11:31 AM #451
PedroBR


Join Date: Jul 2011
Brazy-u,

What is better for you, if I write in english or if I use a translator?

Ce qui est mieux pour vous, si j'écris en anglais ou si j'utilise un traducteur?
PedroBR is offline   Reply With Quote
Old 11-29-2011, 01:01 PM #452
brazy-u


Join Date: Jan 2002
 has been a member for 10 years
PedroBR

écris en anglais c'est mieux

brazy-u is offline   Reply With Quote
Old 11-29-2011, 02:31 PM #453
brazy-u


Join Date: Jan 2002
 has been a member for 10 years
brazy-u is offline   Reply With Quote
Old 11-29-2011, 04:51 PM #454
brazy-u


Join Date: Jan 2002
 has been a member for 10 years


le bouchon est très travaillé pour une bonne préhension et un gain de poid (certainement l’élément du moteur la plus coûteuse)

visse d’accouplement entre le bouchon et le powertube cap via un joint de contact comme sur les clone

bourlet pour un renfort mécanique de la pièce

les trous d’alimentation ne sont pas à cheval sur le cône de butée pour réduire l’usure des bumper
brazy-u is offline   Reply With Quote
Old 12-02-2011, 09:19 PM #455
brazy-u


Join Date: Jan 2002
 has been a member for 10 years









brazy-u is offline   Reply With Quote
Old 12-05-2011, 02:03 PM #456
brazy-u


Join Date: Jan 2002
 has been a member for 10 years














brazy-u is offline   Reply With Quote
Old 12-05-2011, 02:10 PM #457
brazy-u


Join Date: Jan 2002
 has been a member for 10 years
espace raisonnable pour une bonne decente de bille

pour cette petite étude c’est la position
la plus intéressante de la bille suivante
en position d’attente

j’essaye de visualiser quel type de bolt induit
quelle ampleur de mouvement sur la bille
suivante durant leur cycle.
L’objectif final est d’imaginer quel architecture
permettrais à une culasse de spool-valve d’être
aussi bien qu’une Planet Eclipse Cure 3 Bolt
( bien que GEO GST soit déjà une petite
merveille grâce en particulier à ses ADF (mais
se bolt existe déjà))

représentation de l’emplacement idéal

bille logée en attente de propulsion

ici c’est un peu compliqué d’expliquer
ce que j’essaye de représenter :
Pour simplifier la comparaison
d’ampleur de mouvement de la
prochaine bille, je ne l’ai pas placé au
bon endroit (il devrait être un peu plus
en avant mais ça rend le dessin trop
chargé

représentation des risques de scalpage
par la lèvre périphérique du bolt sur la
bille suivante durant la phase de tir
brazy-u is offline   Reply With Quote
Old 12-05-2011, 03:34 PM #458
manknuckle


Join Date: Dec 2011
so confuse with the diagram, but the girl looks HOT lol. got sidetracked withthis page lol
manknuckle is offline   Reply With Quote
Old 12-05-2011, 07:12 PM #459
brazy-u


Join Date: Jan 2002
 has been a member for 10 years






brazy-u is offline   Reply With Quote
Old 12-06-2011, 02:25 AM #460
brazy-u


Join Date: Jan 2002
 has been a member for 10 years






brazy-u is offline   Reply With Quote
Old 12-06-2011, 03:30 PM #461
Spitlebug
I'm rule 34...

Spitlebug's Avatar

Join Date: Sep 2003
Location: The place men fear.
Spitlebug is a Supporting Member
 has been a member for 10 years
Spitlebug donated to help Peyton Trent
Spitlebug has perfected Level 1 in PbNation Pursuit
Spitlebug has perfected Level 2 in PbNation Pursuit
Spitlebug is attending Decay of Nations VI
Quote:
Originally Posted by brazy-u View Post

I see what you are doing there, but the ball is actually concentrically constrained by the feedneck so it can't actually move too much. The biggest problem with balls rolling into open face bolts is the small edge of the bolt accidentally clipping the upper ball.

Roll back is a serious marker problem because on one hand there has to be enough room to chamber a ball, but you don't want too much play between the ball and the bolt face which will exasperate any clipping issues. I don't know of any ideal way to solve the issue, other to say that it is an inherent flaw with loading a round projectile the way we current feed paintball markers.
__________________
Administrator - www.icd-owners.com - For all your ICD needs.
Hyaaaaaaah! Take that Small Talk, may you rot in the fires of paintball hell.
Spitlebug is offline   Reply With Quote
Old 12-06-2011, 04:13 PM #462
thermodynamics


thermodynamics's Avatar

Join Date: Sep 2008
Location: Nashville, TN
thermodynamics has achieved Level 1 in PbNation Pursuit
thermodynamics has achieved Level 2 in PbNation Pursuit
thermodynamics has achieved Level 3 in PbNation Pursuit
Isnt that what Pootys bolts are supposed to fix? I dont have one, but they are flat faced with no place for the ball to roll back into the bolt.

Quote:
Originally Posted by Spitlebug View Post
I see what you are doing there, but the ball is actually concentrically constrained by the feedneck so it can't actually move too much. The biggest problem with balls rolling into open face bolts is the small edge of the bolt accidentally clipping the upper ball.

Roll back is a serious marker problem because on one hand there has to be enough room to chamber a ball, but you don't want too much play between the ball and the bolt face which will exasperate any clipping issues. I don't know of any ideal way to solve the issue, other to say that it is an inherent flaw with loading a round projectile the way we current feed paintball markers.
thermodynamics is offline   Reply With Quote
