Old 10-03-2012, 05:43 PM #85
team_Static_Age


team_Static_Age's Avatar

Join Date: Jun 2005
Location: 805 Souther california
team_Static_Age is playing at Living Legends V
team_Static_Age owns a Planet Eclipse Geo
team_Static_Age supports Team VICIOUS
team_Static_Age is for the Gunfight
Cole chimed in when were talking about this and put it not needed along with a long speach..
team_Static_Age is offline   Reply With Quote
Old 10-05-2012, 04:16 PM #86
Twister60


Twister60's Avatar

Join Date: Oct 2006
Location: Toronto
Twister60 owns a Planet Eclipse Ego
Twister60 has achieved Level 1 in PbNation Pursuit
Twister60 has achieved Level 2 in PbNation Pursuit
Twister60 has achieved Level 3 in PbNation Pursuit
Twister60 is attending Decay of Nations VI
I love that You made a guide, whilst there were older guides, you've kept this alive and did an awesome job.

I have lots of that epoxy steel available that I can ship to whoever needs for free or nearly free. Also, if you dont already have that vent hole drilled, I have a machine shop that works on firearms all day and knows what care a marker needs, that can do it for You.
__________________
[[[Pro Sponsored]]]
Eat. Sleep. Bunker.

Full Body Creation, Machining, Anodizing and Repair + Parts and Service Available
Pods now only $1.00!
07 EGO|Hybrid NXT|PM6|RPM|PMR|3 Quest's
Twister60 is offline   Reply With Quote
Old 10-06-2012, 07:03 AM #87
Jaccen


Jaccen's Avatar

Join Date: Oct 2011
Location: SW Ontario
Will your shop do the Allen screw mod?
Jaccen is offline   Reply With Quote
Old 10-06-2012, 11:12 AM #88
tacxplosion


tacxplosion's Avatar

Join Date: Sep 2007
Location: Guatemala (for real)
Quote:
Originally Posted by Jaccen View Post
Sorry to bump an old thread, but do you have a diagram explaining this? Thanks.

Last edited by tacxplosion : 10-06-2012 at 11:20 AM.
tacxplosion is offline   Reply With Quote
Old 10-06-2012, 01:29 PM #89
Demo2222
.

Demo2222's Avatar

Join Date: Jun 2011
Location: socal
Annual Supporting Member
Demo2222 supports Empire
Is that a prosthetic member? Haha
Nice work I like what you did there
__________________

FOR SALE
2014 VICIOUS AXE
IRONMAN
http://www.pbnation.com/showthread.p...3&goto=newpost
Demo2222 is offline   Reply With Quote
Old 10-06-2012, 03:26 PM #90
tacxplosion


tacxplosion's Avatar

Join Date: Sep 2007
Location: Guatemala (for real)
ZOMG! 1377 p41n7 5k1112 (30 min MS paint)

no, seriously the LPR's cutaway looks oddly phallic now that you mention it. It's about as close to a technical diagram as I cared to draw, since we're not playing with dimensions or threads, it's just a hole bored into the adjustment screw all the way through, I did it to my timmy LPR's on a bench vise with a power drill, it doesn't even have to be perfectly straight; as long as your new hole overlaps part of the washer's.
tacxplosion is offline   Reply With Quote
Old 10-06-2012, 05:33 PM #91
juit
CHEECH IS G@I

juit's Avatar

Join Date: May 2008
Location: mission
Annual Supporting Member
juit supports Team VICIOUS
juit is for the Gunfight
juit posts videos on PbNation
juit has achieved Level 2 in PbNation Pursuit
juit has perfected Level 2 in PbNation Pursuit
I did this purge hole on my drill press
juit is offline   Reply With Quote
Old 10-08-2012, 07:35 AM #92
Jaccen


Jaccen's Avatar

Join Date: Oct 2011
Location: SW Ontario
Thanks for the diagram, tacxplosion. It's very much appreciated. Cheers.
Jaccen is offline   Reply With Quote
Old 12-10-2012, 11:03 AM #93
blueshifty
RIP: Underøath

blueshifty's Avatar

Join Date: Jun 2006
Location: Dallas, TX
I did the LPR purge hole with a 1/16 bit and a drill... I can say that this is a MUCH needed mod. My pressure was dropping pretty bad in PSP, but since the mod the LP drops may 10 psi.Great job on this one juit.

I also did the macroline (tape) mod, but need to get to a chrono to test.

One thing that I did since the stock bolt had some pretty bad wear on the tip is polish the very front. I also added an oring on there as a front bumper. Overall I am VERY pleased with the results.
__________________
Feedback: Old (+4)
blueshifty is offline   Reply With Quote
Old 03-12-2013, 02:27 PM #94
warbeak2099
That is my foot!

warbeak2099's Avatar

Join Date: Jun 2003
Location: Wouldn't u like to know!
 has been a member for 10 years
Wow, the reg vent hole mods are genius and so easy. I'm definitely doing this and testing when I get a new noid for my 06 Quest.
__________________
US Navy Baller
UL'd 07 PMR F/S, PM me if interested!
#12 Italian Baller
“The real test of a man is not how well he plays the role he has invented for himself, but how well he plays the role that destiny assigned to him.”
-Václav Havel
warbeak2099 is offline   Reply With Quote
Old 08-26-2013, 10:14 PM #95
juit
CHEECH IS G@I

juit's Avatar

Join Date: May 2008
Location: mission
Annual Supporting Member
juit supports Team VICIOUS
juit is for the Gunfight
juit posts videos on PbNation
juit has achieved Level 2 in PbNation Pursuit
juit has perfected Level 2 in PbNation Pursuit
OK guys you can do the hole tru the cap I just uploaded new pictures of how I did it
juit is offline   Reply With Quote
Old 09-21-2013, 02:23 PM #96
juit
CHEECH IS G@I

juit's Avatar

Join Date: May 2008
Location: mission
Annual Supporting Member
juit supports Team VICIOUS
juit is for the Gunfight
juit posts videos on PbNation
juit has achieved Level 2 in PbNation Pursuit
juit has perfected Level 2 in PbNation Pursuit
this lpr had to use a bigger diameter oring to seal then it was creeping awful,

the hole fix it

juit is offline   Reply With Quote
Old 12-11-2013, 10:38 AM #97
toptencoach
TopTenCoach

toptencoach's Avatar

Join Date: Sep 2008
Location: USA Vancouver Washington
Annual Supporting Member
Here's my bolt pin mod modeled as close to the one you did that I could get...

toptencoach is offline   Reply With Quote
Old 12-11-2013, 10:43 AM #98
juit
CHEECH IS G@I

juit's Avatar

Join Date: May 2008
Location: mission
Annual Supporting Member
juit supports Team VICIOUS
juit is for the Gunfight
juit posts videos on PbNation
juit has achieved Level 2 in PbNation Pursuit
juit has perfected Level 2 in PbNation Pursuit
takes some time to use that stuff , good work!

Last edited by juit : 12-11-2013 at 11:32 AM.
juit is offline   Reply With Quote
Old 12-15-2013, 01:39 AM #99
warbeak2099
That is my foot!

warbeak2099's Avatar

Join Date: Jun 2003
Location: Wouldn't u like to know!
 has been a member for 10 years
Wait so some pictures have the LPR vent hold on the front of the LPR and others have it on the side. I'm confused, where is the hole supposed to be drilled?
__________________
US Navy Baller
UL'd 07 PMR F/S, PM me if interested!
#12 Italian Baller
“The real test of a man is not how well he plays the role he has invented for himself, but how well he plays the role that destiny assigned to him.”
-Václav Havel
warbeak2099 is offline   Reply With Quote
Old 12-15-2013, 07:47 AM #100
tacxplosion


tacxplosion's Avatar

Join Date: Sep 2007
Location: Guatemala (for real)
Quote:
Originally Posted by warbeak2099 View Post
Wait so some pictures have the LPR vent hold on the front of the LPR and others have it on the side. I'm confused, where is the hole supposed to be drilled?
Anywhere that vents the spring section of the LPR, if you prefer a reversible mod, into the adjustment screw; if you don't really mind, then on the side wall of the LPR is also fine (mine's drilled on the side, though I wish I'd done it through the adjustment screw for looks).
tacxplosion is offline   Reply With Quote
Old 12-15-2013, 11:35 AM #101
juit
CHEECH IS G@I

juit's Avatar

Join Date: May 2008
Location: mission
Annual Supporting Member
juit supports Team VICIOUS
juit is for the Gunfight
juit posts videos on PbNation
juit has achieved Level 2 in PbNation Pursuit
juit has perfected Level 2 in PbNation Pursuit
any place you want it doesn't matter
juit is offline   Reply With Quote
Old 12-16-2013, 01:28 PM #102
warbeak2099
That is my foot!

warbeak2099's Avatar

Join Date: Jun 2003
Location: Wouldn't u like to know!
 has been a member for 10 years
Ah gotcha, makes sense!
__________________
US Navy Baller
UL'd 07 PMR F/S, PM me if interested!
#12 Italian Baller
“The real test of a man is not how well he plays the role he has invented for himself, but how well he plays the role that destiny assigned to him.”
-Václav Havel
warbeak2099 is offline   Reply With Quote
Old 12-29-2013, 09:47 PM #103
toptencoach
TopTenCoach

toptencoach's Avatar

Join Date: Sep 2008
Location: USA Vancouver Washington
Annual Supporting Member
The drilling went real easy by drilling from the back
side, since the taper of the set screw surface kind
of automatically centered the bit. I just put a small
piece of plastic into the head of the set screw, put
my allen key in on top of that so I could hold it and
not have the screw spin, and drilled. Super easy!


Here is the set screw drilled on the HPR:


Here is the set screw drilled on the LPR:
toptencoach is offline   Reply With Quote
Old 01-02-2014, 10:30 PM #104
juit
CHEECH IS G@I

juit's Avatar

Join Date: May 2008
Location: mission
Annual Supporting Member
juit supports Team VICIOUS
juit is for the Gunfight
juit posts videos on PbNation
juit has achieved Level 2 in PbNation Pursuit
juit has perfected Level 2 in PbNation Pursuit
those regs gonna rock
juit is offline   Reply With Quote
Old 01-03-2014, 01:08 AM #105
icweiner
iseewhiner!

icweiner's Avatar

Join Date: Sep 2005
Location: The 865
Quote:
Originally Posted by toptencoach View Post
The drilling went real easy by drilling from the back
side, since the taper of the set screw surface kind
of automatically centered the bit. I just put a small
piece of plastic into the head of the set screw, put
my allen key in on top of that so I could hold it and
not have the screw spin, and drilled. Super easy!


Here is the set screw drilled on the HPR:


Here is the set screw drilled on the LPR:
I don't own a quest.... but I saw just mentioned he did this on his Timmy. So I could drill 1/16 holes in the lpr ajuster screw and reg on my alias and instantly see increased recharge rates? sounds to good to be true lol
__________________
MY FEEDBACK
icweiner is offline   Reply With Quote
